Series: PX SD
The pump switches on automatically when the pressure drops below the minimum set value. When water demand ends, the pump will fill up the tank and then it turns off when the pressure reaches the maximum set value.
Pump body: AISI304
Base: Cast Iron
Impellers: AISI304
Shaft: AISI304 The mechanical seal is inspectable without disassembling the pump
Max. Head: 249m
Max. Flow: 150m³/h
Liquid temperature: from -20°C to +120°C
Poles: 2
Protection degree: IP55
Voltage: 1x230V 3x 380V
ADVANTAGE:
Pressurisation booster sets
