Series: AV RXY E
• Civil and industrial waters handling plants
• Pressurization plants
• Water supply from rain water tanks or reservoirs, 5″ water wells,
roman wells, basins and watercourses
• Sprinkler systems
• Rain water system
External jacket: AISI 304
Impellers: Technopolymer
Pump shaft: AISI 304
Max. Head: 61,5 m
Max. Flow: 6 m³/h
Max. Liquid temperature: 35°C
Discharge head: 1″ 1/4
Max. Depth immersion: 20m
Insulation class: F
Poles: 2
Protection degree: IP68
Voltage: 220-230V (1ph)
ELECTRONIC MONOBLOC PUMPS
